CNC Lathe with Y-Axis
CNC Lathe with Y-Axis for sale
Overview
The DMG Gildemeister CTX 420 Linear V6 is a high-end CNC lathe with Y-axis, designed for precision machining and advanced multi-tasking operations. Built for modern manufacturing environments, this machine combines speed, power, and flexibility, making it ideal for producing complex components in a single setup. This used CNC lathe machine is a great option for workshops looking to upgrade their capabilities with a proven, high-performance solution.
Key Specifications
- Maximum turning diameter: 680 mm
- X-axis travel: 260 mm
- Y-axis travel: 40 mm
- Z-axis travel: 635 mm
- Spindle bore: 68 mm
These specifications make the machine suitable for a wide range of medium to large precision components.
Performance & Spindle
The lathe is equipped with a powerful main spindle reaching speeds of up to 5000 rpm, supported by a strong 35 kW motor. This allows for efficient cutting, smooth finishes, and reliable performance across various materials.
Sub-Spindle & Multi-Tasking
The sub-spindle operates at speeds up to 7000 rpm, enabling complete machining of both sides of a workpiece without repositioning. This feature significantly reduces cycle times and improves overall productivity.
Tooling & Flexibility
- Turret capacity: 12 tool positions
- C-axis and Y-axis functionality for complex machining
With live tooling and multi-axis capability, the machine can perform turning, milling, drilling, and tapping in one setup, making it highly versatile.
Build & Dimensions
- Length: approx. 4900 mm
- Width: 2500 mm
- Height: 2100 mm
- Weight: approx. 6500 kg
The solid construction ensures excellent stability, even during high-speed and heavy-duty operations.
Additional Features
- Chip conveyor for efficient chip removal
- Compact yet robust design for industrial use
Applications
The CTX 420 Linear V6 is ideal for:
- Complex component manufacturing
- Automotive and aerospace parts
- High-precision engineering work
- Medium to high-volume production
Conclusion
The DMG Gildemeister CTX 420 Linear V6 CNC lathe is a powerful and flexible machine that delivers precision, efficiency, and advanced machining capability. It’s an excellent investment for workshops aiming to improve productivity and handle more complex jobs with ease.
