2000mm BERNARDO CNC Lathe

Description

2000mm BERNARDO CNC Lathe

2000mm BERNARDO CNC Lathe for sale

Overview

The BERNARDO CY-K660T CNC lathe is a powerful and versatile machine designed for precision turning and heavy-duty workshop use. With its long 2000 mm turning length and modern features, this lathe is ideal for engineering companies, maintenance workshops, and production environments. It combines strong performance with user-friendly controls, making it suitable for both experienced operators and those upgrading to CNC-supported machining.

Key Specifications

• Turning diameter: 660 mm
• Turning length: 2000 mm
• Swing over bed slide: 460 mm
• Spindle bore: 105 mm
• Speed range: 25 – 1600 rpm
• Tailstock quill stroke: 235 mm
• Tailstock taper: MK5
• Motor power: 7.5 kW

These specifications allow the machine to handle a wide range of workpieces, including long shafts and large-diameter components.

Performance & Control

The lathe is equipped with a 3-axis digital display (ES-12 V with LCD), giving you clear and accurate positioning for better machining results. A frequency converter ensures smooth speed adjustments, while rapid traverse in longitudinal and cross directions helps reduce machining time and improve efficiency.

Build & Capability

The BERNARDO CY-K660T is built with a solid and stable structure, ensuring reliable performance during demanding operations. Its wide speed range and strong motor provide the flexibility needed for both roughing and finishing tasks.

Equipment & Features

This machine comes fully equipped with a wide range of useful accessories, including:

• 3-jaw steel chuck (315 mm / D8)
• 500 mm clamping disk
• Fixed steady rest (max. 180 mm passage)
• Follow rest (max. 100 mm passage)
• Quick-change tool holder with 4 inserts
• Coolant system for improved cutting performance
• LED machine light for better visibility
• Foot pedal with brake function (CE compliant)
• Slip clutch for added safety
• Chip back wall and cable routing via energy chain

It also includes initial oil filling with Shell Tellus 46, ensuring the machine is ready for operation.

Conclusion

The 2000 mm BERNARDO CY-K660T CNC lathe is a dependable and well-equipped machine that offers power, precision, and ease of use. It’s an excellent choice for workshops looking to handle larger workpieces while maintaining high-quality machining results.
