Hydraulic Straightening Press

Description

Hydraulic Straightening Press – TMW 6000 50 Hydraulic Straightening Press for Sale

Hydraulic Straightening Press

Overview

The TMW 6000 50 Hydraulic Straightening Press is a practical and efficient solution for straightening long and heavy workpieces. Designed for industrial and workshop use, this 50 ton hydraulic straightening press offers flexibility, precision, and reliable performance. Its extended working length makes it especially suitable for handling large components such as beams, shafts, and structural parts.

Key Specifications

• Press capacity: 50 tons
• Stroke: 400 mm
• Working length (between columns): 6000 mm
• Working width (sideways): 600 mm
• Installation height: 700 mm

These specifications provide ample space and force for a wide range of straightening applications.

Performance & Operation

The press is equipped with a movable hydraulic cylinder, allowing it to be shifted sideways along the working area. This feature improves flexibility and enables precise positioning when working on long or uneven components. The 400 mm stroke ensures sufficient travel for correcting deformation in different materials and thicknesses.

Build & Design

• Machine weight: approx. 3.6 tons
• Space required (L x W x H): approx. 6.7 x 1.4 x 3.2 m

The strong frame construction ensures stability during operation, reducing deflection and improving accuracy. Its long bed design supports large workpieces while maintaining consistent pressure across the working area.

Features & Advantages

• Sideways movable cylinder for flexible operation
• Long working area (6000 mm) for large components
• Simple and reliable hydraulic system
• Compact width for easier workshop integration

These features make the machine easy to operate while maintaining high efficiency.

Applications

The straightening press is ideal for:

• Straightening long metal beams and profiles
• Repair and maintenance work
• Steel fabrication and construction
• Workshop and industrial use

Conclusion

The Straightening Press is a reliable and versatile machine for handling long and heavy workpieces. With its strong pressing force, movable cylinder, and extended working length, it offers an efficient solution for straightening tasks in a variety of industrial applications.
